Tacoma Ultimate Package Fitment Chart


2005-2023 Tacoma DCSB
Leaf Pack Est. Lift Amount Axle Tube to Frame Bottom
Stock 3/1 - 0lbs 0in 8.25in
Archive LD - 0lbs 2.25in 10.5in
Archive LD - 300lbs 1.5in 9.75in
Archive MD - 0lbs 3.0in 11.25in
Archive MD - 300lbs 2.5in 10.75in
Archive MD - 600lbs 2.0in 10.25in
Archive HD - 600lbs 3.0in 11.25in
Archive HD - 1250lbs 2.0in 10.25in
Archive XD - 1250lbs 3.0in 11.25in
Archive XD - 1750lbs* 2.5in 10.75in
Archive MAXD - 1750lbs* 3.0 11.25in
Archive MAXD - 2500lbs* 2.5in 10.75in
*Disclaimer: Archive Garage in no way recommends exceeding Toyota's GVWR.  Owner assumes all risk when exceeding Toyota's GVWR or GAWR. Archive springs give your heavy Tacoma safer handling

Recommended Shocks (Confirmed Fit & Performance)
Shock Brand Part Number
Accutune Fox Factory RR 2.5x12 Fox 981-25-002-ARG
Accutune Fox Factory RR 2.5x14 Fox 981-25-003-ARG
AccuTune Fox Factory RR DSC 2.5x12 Fox 981-25-002-ARG
AccuTune Fox Factory RR DSC 2.5x14 Fox 981-25-003-ARG
AccuTune King RR 2.5x12 King King PR2512-SS
AccuTune King RR 2.5x14 King King PR2514-SS
AccuTune King RR 2.5x12 w/ adjuster   King King PR2512-SS-A
AccuTune King RR 2.5x14 w/ adjuster King  King PR2514-SS-A
ADS Smooth Body 2.5x12 ADS 250-SBR12-W00
ADS Smooth Body 2.5x12 w/adjuster ADS 250-SBR12-WA0
*If using HD Springs or XD 12in is best
*For additional options reach out to shock company to confirm with specs below
Shock Specs Needed
2.5" & 3.0" Smooth Body Shock Remote Resi
Shock Travel Fittings/Spacers
12-14in Standard rod-end shocks (1.5" wide, 1/2" bolt)
2.5" Bypass
Note: We do not guarantee that all bypasses will fit due to the numerous brands and possible custom layouts you can order.
-Many have successfully installed 2.5" bypasses, but 3.0 bypass will not fit
-Best tube layout: bypass tubes placed forward towards engine, with remote hose elbow towards the rear bumper.
-We recommend only 12" travel bypasses because shock piston at normal ride height needs to be below comp. tube ports/zones.
Wheel Fitment Needed (Smoothy)
Wheel Backspacing
4.75" BS + 1.25" Spacer for 285s
3.5" BS - no spacer for 285s
3.5" BS + 1.25" for 35x12.5s or 315s
Offset Visualizer App




How To Measure Rear Lift
